The DS-SA60 model is a specialized machine designed to compare the chip material's scanned MAP image with the loaded MAP file, and then sort chips with the same BIN number onto the same wafer. The machine sorts chips based on the optoelectronic parameters obtained from the chip tester and the product appearance inspection results from the AOI system. It is widely used in sorting LED chips, IC chips, optical filters, lenses, SM components, capacitors, and other materials.

• High Production Efficiency and Stable Placement Precision: Ensures consistent, high-speed production and stable alignment


• Simple Operation: Allows for easy setup and the ability to define the search range, chip shape, and wafer spacing


• Flexible Modes: Supports both reordering and sorting functions, providing versatility for various tasks


• Easy Nozzle Alignment Calibration: Simple and user-friendly nozzle position calibration method


• Automatic Nozzle Contact Height Measurement and Setting: The system automatically measures and sets the contact height of the nozzle for optimal performance


• Automatic Compensation for Position and Angle Deviations: Automatically corrects for deviations in the positioning and angles of chips during sorting


• Comprehensive Production Reporting: Provides a complete set of production data reports for analysis and tracking


• Adjustable Nozzle Pressure: Allows for customizable nozzle pressure based on the specific requirements of the material being sorted


• Customizable Development: Supports bespoke developments and configurations based on customer needs
