The machine can picks up LD bars and spacers from wafer frame and stack them precisely into coating fixture. Designed for arranging Bar strips in the optical communication and highpower laser chip industries onto coating jigs for auxiliary processes.

Bar and Spacer Materials: Si, GaAs, InP, and other semiconductor materials.

• High Speed and Precision: Equipped with linear motors, achieving a production efficiency of 12 seconds per group


• Visual Positioning: Full-vision alignment system accurately identifies the position of each product, capable of detecting broken bars and chipped edges


• Real-Time Demonstration: Vision system supports real-time mode switching, enabling visible and controllable adjustments for debugging and fine-tuning


• Class 100 Dustproof Environment: Constructed with a mirror-finished stainless steel frame and high-efficiency air filtration units to maintain a clean workspace


• High Efficiency Output: Dual workstations and dual suction nozzles for pick-and-place operations, combined with alternating dual coating jig workflows for uninterrupted production, meeting high-volume application demands


• Precision Jigs: Features patented suction nozzles, Jig Base, and jig-matching designs for optimal compatibility and performance
