The laser projector assembly line is developed on the basis of the vehicle projection project, and is compatible with the assembly and test automation production line of many products, saving manpower and improving the quality and stability of the process. The line body is mainly composed of transmission system, external feeder, intelligent locking module, high-speed and high-precision assembly module, high-precision dispensing module, focusing/missing edge test module, vision system and other functional modules.

• Easy to Operate, quick modeling with automatic template generation for similar products


• Compatible with a variety of products, support fast tangential conversion


• Support secondary detection in offline state, support customized report modification


• External tray clip feeder feed


• The upper and lower feeding tracks are arranged inside the equipment to realize non-stop feeding


• CCD system is configured for visual aid positioning


• Electric batch locking accuracy: ±5%, assembly accuracy: ±0.05mm


• Equipped with UV curing unit, water cooled


• Manual electric batch with track error prevention function


• PC control system
